Durable High Quality Powder Coated Drive In Racking System For
Warehouse Storage
Product Description
1. High quality powder coated drive in racking sysytem are applied
in industrial warehouse storage using entering-in forklifts for
products loading and unloading.
2. Suitable for large quantity products with less items, drive in
pallet racks make better space utilization rate with compact
storage density following LIFO material handling method.
3. Usually, the storage depth for each lane is less than 8 pallets
for safety and stability.
4. Supported rails in drive in pallet racks are specially designed
for pallet loads deposit and withdraw.
5. For warehouse security, protective guiderails that can
facilitate the forklift smooth movement are highly recommoned in
the drive in racking system.
6. Drive through pallet racks are another transformation of drive
in racks with two entry points of each bay, thus, different from
the former, drive through racks support both FIFO and LIFO stock
rotation principles.
More Details about Drive-in Pallet Racks
| Pallet rack type | Forklift drive in pallet racks |
| Dimensions | Customized sizes with height, bay width and depth |
| Load capacity | Ranged from 1000kg-2000kg per pallet as customers' demand |
| Material | Powder coated roll-formed Q355 steel |
| Material handling | Last-in/First-out material handling method |
| Safety accessories | Column protectors, entry guides, frame protectors, guide rails |
| Components | Upright frame(upright, horizontal bracing, diagonal bracing),
beams, pallet rails |
Production Specifications
1. Ironstone drive in pallet racks are commonly manufactured with
high quality Q355B steel. with powder coated surface treament.
2. For frezzers and special required warehouses, Q345 steel is also
available for customized option.
3. Drive in pallet rack major components such as upright frames,
beams and rails are often powder coated for corrosion protection.
4. More cost-saving galvanized rack components are also optional
for specialized request.
5. Upright frames of drive in racks can be engineered with
different holes, section sizes and material thickness with
different load capacities.
6. Supported rails can adjusted with varified pitch distances
including 50mm, 50.8mm, 75mm and 76.2mm.
7. Coberls for pallet rail support can be sigle-sided and
double-sided with strong rigidity.
8. High grade bolts and nuts for rack installation are attached to
the rack systems free for our customers' benefits.
9.Ironstone drive in racks have been approved with related
certifications including RMI/CE/ISO/TUV/AS4084-2012.
Details for Design and Quote
For accurate drive in rack design and quote, related answers are
welcomed from our customers for the following questions.
1. Do you have the drawing of your warehouse layout with details?
2. What's the available space for your required drive in racks?
3. What are the size and weight of your future stored pallet loads?
4. What are the expected dimensions of the drive in rack, such as
the rack height, width and depth?
5. How many layers do you want to have for each storage bay?
6. What's the expected load capacity of the drive in rack?
7. What's your budget for the racking system?
8. What kind of forklift do you have or want to use in the future?
To sum up, drive in racking system is a trustworthy, high density,
economical storage solution that can optimize your facility space
and maximize your profits. If you have large amount of commodities
with less SKUs, you can consider cost-saving drive in racks. You
will get your perfect drive in racking solution from Ironstone with
convenient but cost-effective one-stop services.
